Power Source: Two 1.5 V AAA alkaline batteries
Display: LCD with backlight
Memory: Stores up to 400 test results
External Output: Test strip port
Operating Conditions
Blood Glucose Testing:
•    Temperature: 8°C to 45°C (46.4°F to 113°F)
•    Humidity: 10% to 90% RH (non-condensing)
β-Ketone Testing:
•    Temperature: 10°C to 40°C (50°F to 104°F)
•    Humidity: 10% to 85% RH (non-condensing)
Sample Size and Reaction Time
Blood Glucose Test:
•    Sample size: 0.5 μL
•    Test time: 5 seconds
β-Ketone Test:
•    Sample size: 0.8 μL
•    Test time: 10 seconds
Measurement Units
Blood Glucose Test:
•    mg/dL or mmol/L
β-Ketone Test:
•    mmol/L
Measurement Range
Blood Glucose Test:
•    10–800 mg/dL (0.56–44.4 mmol/L)
β-Ketone Test:
•    0.1–8.0 mmol/L

Please refer to the meter Owner's Manual for detailed operating instructions.

1. Turn on the meter by inserting a test strip.
2. Select Dog or Cat mode.
3. Lance the selected puncture site.
4. Gently squeeze the puncture site to obtain a drop of blood.
5. Carefully apply the blood sample to the absorbent opening of the test strip at a slight angle.
6. Place the meter flat on a table and wait for the test result to appear on the display.
7. Eject the test strip by pressing the eject button on the side of the meter.
8. Remove the used lancet by first twisting off the lancing device cap. Safely dispose of the used lancet according to local regulations.

•    Tests for blood glucose and β-ketones
•    Automatic test strip identification
•    Measures β-ketone levels to help diagnose and monitor diabetic ketoacidosis (DKA)
•    Advanced Autocode® Technology eliminates the need for a coding chip
•    Test strip ejector for touch-free disposal
•    Backlit display for easy reading in low-light conditions
